System Features

• 120 VAC, 20 amps
• Standard system maximum board size:- 11" x 20" (28cm x 51cm); with upper basket removed maximum board size is increased to 18" x 20"
• Modular polypropylene cabinet
• DI water compatible
• 120 VAC, 20 amps
• On-board wash/rinse heated reservoir
  - Ambient to 140° F
  - Mage drive pump
  - Auto fill and level control
• On-board wash/rinse heated reservoir
  - 3.5 gallon capacity
  - Heater to maintain process temperature
• Small footprint of 26" deep x 45" wide x 63" tall
• Maneuverable with caster based chassis
• Built-in power transfer to drain, provides 15 foot of head
• Computer Control
  - Controls number of process cycles
  - Computer entry of resistivity criteria
  - Visual Basic on Windows XP platform
  - Automatic programmable response when
  - Selected resistivity reading is achieved
  - Manually set temperature control of process reservoir, temperature monitoring of cleaning process
  - Networkable

Process Features
• Cleans and tests automatically
• Electromechanical Controller
• Selectable Processes: Prewash, Wash, and Dry
• Selectable Pass/Fail final resistivity: 100K, 200K, 500K, 1M
• Conforms to NFPA 79

System Configurations
• AquaBatch 1000 OL: Open loop wash, Open Loop Rinse, Water Only
• AquaBatch 1000CL: Closed loop wash, Closed Loop Rinse, Water Only
• AquaBatch 1500 OL: Closed loop wash, Open Loop Rinse, Aqueous Mixtures
•AquaBatch 1500 CL: Closed loop wash, Closed Loop Rinse, Aqueous Mixtures
